Small Glass Laminating Machine

LPFM-S700-100B
Standard model, low-end configuration. Customized configuration and models of different sizes can be customized upon request.

Scope of application This equipment is mainly suitable for 2~20mm acrylic plate/glass/light guide plate, 0.03~0.1mm protective film, explosion-proof film. Product features 1. Adopt stepless speed regulation motor, adjustable speed 2. Double-sided lamination, mechanical tension adjustable 3. Adjustable thickness, front and rear rollers are adjusted separately 4. The discharging rubber roller platform is powered, which is convenient for film cutting 5. The pressure roller strength is manually adjusted, and the operation is simple and convenient 6. The pressure is freely adjustable, and the thickness of the laminating product is adjustable 7. The feeding conveyor belt platform uses a positioning wheel for positioning 8. It can be fed on both sides, or on one side 9. It has an advance and retreat function, which can ensure that the product can be reversed when necessary.
LPFM - S700 - 100B
Name
Specifications
Unit
Transfer speed
0~15 (adjustable)
m/min
Film width
660
mm
Maximum film thickness
15
mm
Cot diameter
100
mm
Coating length
700
mm
Belt width
700
mm
In/Out Table Length
1200
mm
Platform height
750
mm
Using power
220
V
Power (motor)
180
KW
Maximum film diameter
300
mm
Diameter of film coated roller
150
mm
Applicable product specifications
300×200~1500×600
mm
Capacity
>600
pcs/h
Equipment weight
200
kg
Device Dimensions
2540×1060×1150
kg

LPFM - S700 - 100B
Name	Specifications	Unit
Transfer speed	0~15 (adjustable)	m/min
Film width	660	mm
Maximum film thickness	15	mm
Cot diameter	100	mm
Coating length	700	mm
Belt width	700	mm
In/Out Table Length	1200	mm
Platform height	750	mm
Using power	220	V
Power (motor)	180	KW
Maximum film diameter	300	mm
Diameter of film coated roller	150	mm
Applicable product specifications	300×200~1500×600	mm
Capacity	>600	pcs/h
Equipment weight	200	kg
Device Dimensions	2540×1060×1150	kg
