Automatic Cutting and Laminating Machine

Automatic Cutting and Laminating Machine

FM-S700-80C
Applicable to 0.2~4mm thick home appliance glass, PVC film, acrylic board, hardware board, covered with double-sided tape or protective film

Consult

Features
Technical Indicators
Overall Dimension

1. There is an adjustable positioning baffle for feeding, and you only need to lean against this baffle when unloading. 2. The bottom of the conveyor belt is padded with a stainless steel plate to make the platform flat, single-sided lamination, the lamination effect is uniform and free of bubbles. 3. The lamination pressure is pneumatically adjusted, the lamination thickness is adjustable and easy to adjust, the film is installed on the air shaft, and the film roll has the function of automatically collecting waste film. 4. There is a set of dust removal devices before the product is laminarized to effectively remove dust from the upper surface of the product. The dust removal device uses a cylinder to adjust the thickness. 5. The lamination power and waste collection motor are driven by speed-regulating motors, with stepless speed regulation. 6. There is an automatic cutting function after lamination, using a servo module with a single knife to cut back and forth.
FM-S700-80C
Name
Specifications
Unit
Diameter of laminating rubber roller
80
mm
Lagging length
700
mm
Platform Roller Spacing
150
mm
Lamination width
660
mm
Lamination speed
1~20
mm
Lamination thickness
0.2~4
mm
Belt width
700
mm
Maximum film diameter
300
mm
Maximum discharge diameter
300
mm
Maximum waste diameter
300
mm
Max unwinding tension
50
N
Feed table length
700
mm
Discharge table length
500
mm
Total weight of equipment
480
kg
Platform height
750
  mm
Crop width
600
  mm
Cutting accuracy
±1
  mm
Cutting speed
700
  mm/s
Crop output platform length
500
  mm
Use air pressure
4~6
  kg/cm²
Using electric
220
  V
Total power
650
  KW
Device Dimensions
2500×1050×1150
  mm

FM-S700-80C
Name	Specifications	Unit
Diameter of laminating rubber roller	80	mm
Lagging length	700	mm
Platform Roller Spacing	150	mm
Lamination width	660	mm
Lamination speed	1~20	mm
Lamination thickness	0.2~4	mm
Belt width	700	mm
Maximum film diameter	300	mm
Maximum discharge diameter	300	mm
Maximum waste diameter	300	mm
Max unwinding tension	50	N
Feed table length	700	mm
Discharge table length	500	mm
Total weight of equipment	480	kg
Platform height	750	mm
Crop width	600	mm
Cutting accuracy	±1	mm
Cutting speed	700	mm/s
Crop output platform length	500	mm
Use air pressure	4~6	kg/cm²
Using electric	220	V
Total power	650	KW
Device Dimensions	2500×1050×1150	mm
